Transmit & Reflect Polarizing Microscope

Specification:
Swing-out NA0.9/0.25 Abbe Condenser With Iris Diaphragm & Filter
Bertrand Lens, Focus/Center Adjustable Sliding In/Out Of Optical Path
12V/50W Halogen Lamp With Iris Aperture Diaphragm And Iris Field Diaphragm, Brightness Adjustable
Attachable Mechanical Stage, Moving Range 30x40mm
Rotatable Analyzer With Gradation 0°-360°, 360° Rotatable Under The Condenser
Head: Seidentopf Binocular Viewing Head, Inclined at 30°
Seidentopf Trinocular Viewing Head, Inclined at 30°
Eyepiece: WF10x/20 With Cross Hair, Diopter Adjustable, Dia.23.2mm, 1pcs
WF10x/20 With Graticule, Diopter Adjustable, Dia.23.2mm, 1pcs
WF10x/20, Diopter Adjustable,Dia.23.2mm, 2pcs
Objective: Infinity Plan Achromatic Objective 4x,10x for Reflected/Transmitted System
Infinity Plan Achromatic Objective 20x, 40x, 60x for Transmitted System
Infinity Plan Achromatic Objective 20x, 40x, 60x for Reflected System
Nosepiece: Backward Quadruple Nosepiece, Center Adjustable
Focusing: Coaxial Coarse & Fine Adjustment, Range 24mm,Fine Division 0.002mm
Stage Attachable Mechanical Stage, Moving Range 30x40mm
Diameter Φ160mm, Graduated in 1° Increments, Minimum resolution 6’ when using vernier scale
Analyzer: Rotatable Analyzer With Gradation 0°-360°
Polarizer: 360° Rotatable Under The Condenser
Bertrand Lens Bertrand Lens, Focus/Center Adjustable Sliding In/Out Of Optical Path
Optical Compensator λ Slip（First Class Red）, 1/ 4λ Slip, Quartz Wedge
Condenser Swing-out NA0.9/0.25 Abbe Condenser With Iris Diaphragm & Filter
Transmit Light 12V/20W Halogen Lamp, Brightness Adjustable, With Filter, Upgradable To 5W LED
Reflect Light 12V/50W Halogen Lamp With Iris Aperture Diaphragm And Iris Field Diaphragm, Brightness Adjustable
Adapter C-Mount 0.4x
Filter Blue Filter
